Aluminium Curtain Wall

Aluminum Store Front Framing

ThermaWall TW2200

  • 2 inch (50.8 mm) Sight Line
  • Mullion depths from 50.8 mm (2”) to 127 mm (5”)
  • Conventional captured and structural silicone glazed (SSG) options
  • High performing polyamide thermal break provides improved U-factor and resistance to condensation
  • Dual or Triple glazed options
  • Compatible with all Alumicor operable windows, doors, etc.
  • A variety of pressure plate caps are available
  • Custom offset pressure plate
  • Alumicor glass support eliminates concerns of dead loads imposed upon thermal breaks
  • Proprietary gasket provides improved thermal performance

ThermaWall 2600

  • 2 1/2-inch (63.5 mm) Sight Line
  • Mullion depths from 2 7/8 inches (73 mm) to 10 inches (254 mm)
  • Conventional captured and structural silicone glazed (SSG) options
  • Dual and Triple glazed options
  • Combination splice and “T” anchor available
  • Polyamide thermal break provides improved U-factor and resistance to condensation
  • Compatible with Alumicor operable windows, doors, etc.
  • A variety of pressure caps are available
  • Alumicor glass support eliminates concerns of dead loads imposed upon thermal breaks
  • Proprietary gasket provides improved thermal performance
  • Drop-in horizontal available

ThermaWall SM 2600

  • High-performance, pre-fabricated, pre-glazed split-mullion curtainwall with a 2 1/2-inch (63.5 mm) profile
  • Mullion depths of 5 1/4 inches (133.5 mm) and 6 5/8 inches (168.3 mm)
  • Available as either double or triple glazed
  • Split mullion and expansion/stack horizontal
  • Pre-glazed capability allows shop-fabricated quality control
  • Alumicor glass support eliminates concerns of dead loads imposed upon thermal breaks
  • Four-sided structural silicone glazed (SSG) capability
  • Anchor options from complex to simple to suit any project budget
  • Compatible with Alumicor operable windows, doors, etc.
  • A variety of pressure plate caps are available
  • Tested to AAMA 501 requirements

VersaWall 2500

  • 2 1/2” (63.5 mm) Sight Line
  • A large variety of mullion depths from 2 7/8” (73 mm) to 10 inches (254 mm)
  • Suitable for almost any conventional-capped or structural silicone glazed (SSG) application
  • Rain screen, pressure-equalized design
  • Conventional captured and Two or Four-sided SSG options
  • High span 10-inch (254.0 mm) back mullion in SSG or conventional captured
  • “F” and “T” anchors available; combination splice and “T” anchor also available

VersaWall MidLine 2200

  • 2” (50 mm) Sight Line
  • Mullion depths from 2” (50.8 mm) to 5” (127mm)
  • Rain screen, pressure-equalized design
  • Suitable for storefront applications as well as low-rise curtainwall designs
  • Optional fiberglass pressure plate for enhanced thermal performance
  • Available as a split-mullion ribbon window system with two-sided structural silicone glazed (SSG) option
  • “F” and “T” anchors available
  • Thermally broken version available (see ThermaWall TW2200)
